Quick Specs
Specifications
| Product Model | G31F-1744NP-4L |
|---|---|
| Processor Collection | Intel 12th / 13th Gen Processors |
| Socket | FCBGA1744 |
| Memory Type | DDR4 SO-DIMM |
| Maximum Memory Capacity | 2 × 32GB, up to 64GB |
| Maximum Memory Frequency | 3200 MT/s |
| SATA | 1 × SATA 3.0, 6Gb/s |
| M.2 Storage | 1 × M.2 Key-M 2280 |
| Ethernet | 4 × 2.5GbE RJ45 LAN |
| Network Controller | 4 × Intel I226V |
| Front Panel I/O | 4 × RJ45 LAN, 1 × RJ45 COM, 1 × Jack DC_IN |
| Back Panel I/O | 4 × USB-A 3.0, 1 × HD, 1 × DP, 1 × SIM Card Slot, 2 × Reserved Antenna Holes |
| Display Output | 1 × DP, 1 × HD |
| Graphics | Intel UHD Graphics |
| Console | 1 × RJ45 COM, RS232 |
| Expansion Interface | 1 × mPCIe |
| SIM | 1 × SIM Card Slot |
| Cooling Method | Active Cooling, 1 × Chassis Fan |
| Chassis Size | 178 × 126 × 56 mm |
| Motherboard Size | 120 × 120 mm |
| Weight | Equipment Weight: 1.25 KG; Package Weight: 1.85 KG including accessories |
| Power Mode | DC 12V 7A for Pentium / i3; DC 12V 10A for i5 / i7 |
| Operating Temperature | 0°C to 50°C |
| Operating Humidity | 5% to 90% relative humidity, non-condensing |
Typical Applications
Network Security Gateway
Four Intel I226V 2.5GbE LAN ports and high-performance Intel 12th / 13th Gen processing make it suitable for firewall appliances, VPN gateways, UTM systems, routing, network isolation, and multi-WAN security deployments.
Edge IoT Gateway
SIM support, mPCIe expansion, 4 × 2.5GbE connectivity, DC 12V input, and compact chassis design make it suitable for edge IoT gateways, remote communication nodes, and industrial data collection systems.
Small Virtualization Platform
Supports up to 64GB DDR4 memory, M.2 SSD storage, SATA 3.0, and 4 × 2.5GbE LAN, making it suitable for compact virtualization, lightweight edge services, lab routers, and distributed network applications.
Embedded Solutions
Compact Nano-ITX platform, active cooling, M.2 storage, SATA expansion, RJ45 COM, SIM support, mPCIe, and DP+HD display outputs make it suitable for embedded network appliances and custom industrial systems.
