Quick Specs
Specifications
| Product Model | B760-8LAN Motherboard |
|---|---|
| Chipset | Intel B760 Chipset |
| Processor Collection | Intel 12th / 13th / 14th Gen Processors |
| Socket | FCLGA1700 |
| Memory Type | 2 × DDR5 SO-DIMM |
| Maximum Memory Capacity | 2 × 48GB, up to 96GB |
| Maximum Memory Frequency | 4800 MT/s |
| SATA | 4 × SATA 3.0 |
| SATA Power | 4 × SATA Power Sockets |
| M.2 Storage | 2 × M.2 Key-M 2280, PCIe Gen4 x4 / PCIe Gen3 x1 |
| Ethernet | 8 × 2.5GbE RJ45 LAN |
| Network Controller | 8 × Intel I226V |
| PCIe Expansion | 1 × PCIe x16, PCIe 5.0; 1 × PCIe x4, PCIe 4.0 |
| mPCIe | 1 × mPCIe with PCIe 3.0 Signal; 1 × mPCIe with USB 2.0 Signal |
| M.2 Key-B | 1 × M.2 Key-B 3052, USB 3.0 Signal |
| Backplane I/O | 4 × USB-A 3.2 10Gb/s, 1 × RJ45 COM-RS232, 8 × RJ45 LAN, 1 × Power Button, 1 × Jack DC 5.5/2.5mm |
| Display Header | 1 × J_VGA, 1 × J_HDMI, 1 × J_eDP |
| Graphics | Depends on the Processor |
| Console | 1 × RJ45 COM-RS232 |
| Onboard USB | 1 × USB-A 2.0, 2 × F_USB 2.0 Headers expandable to 4 × USB 2.0 ports |
| SIM | 1 × SIM Card Slot |
| Fan Headers | 1 × CPU_FAN, 3 × SYS_FAN |
| Industrial Headers | 1 × F_PANEL, 2 × J_COM, 1 × J_GPIO or J_LPT, 1 × J_I2C, 1 × J_TPM |
| Super I/O Chip | IT8625E |
| Power Supply Mode | DC 24V via 1 × ATX 24V 4-pin Connector or 1 × Jack DC 24V |
| Motherboard Size | 187 × 190 mm |
| Operating Temperature | -20°C to 60°C |
| Operating Humidity | 0% to 90% relative humidity, non-condensing |
Typical Applications
Enterprise Security Gateway
Eight Intel I226V 2.5GbE LAN ports support LACP, multi-WAN, VLAN, virtual bridge, routing, firewall, VPN, SD-WAN, UTM, and enterprise network segmentation applications.
Industrial Automation Control
COM, GPIO or LPT, I2C, TPM, SIM, multiple fan headers, DC 24V power input, and wide-temperature operation make it suitable for factory network control, industrial gateways, machine communication, and automation management systems.
Edge Computing Nodes
Intel 12th to 14th Gen processor support, DDR5 memory up to 96GB, dual M.2 storage, SATA expansion, and 8 × 2.5GbE connectivity provide a powerful platform for edge computing, data processing, and distributed network services.
Server Cluster
PCIe 5.0 x16, PCIe 4.0 x4, high-speed storage, 8 × 2.5GbE LAN, and rich expansion interfaces make it suitable for server clusters, virtualization nodes, network service hosting, traffic management, and data center edge infrastructure.
