Network Routing and Security
The 4-port 2.5GbE provides high-speed network aggregation and load balancing, making it suitable for installing OpenWRT or pfSense, building a home/small office firewall or VPN server, and the fanless design ensures quiet operation.
Edge Computing and IoT Gateway
An onboard SIM card slot and reserved antenna hole support Cellular/Wireless/BT integration. The mPCIe expansion slot facilitates the addition of wireless modules, enabling data collection and real-time transmission for industrial sites, smart cities, or vehicle monitoring.
Small Virtualization Platform
With multiple LAN and USB interfaces, it supports lightweight virtualization or lab network verification environments.
Embedded and Custom Applications
Its compact size, passive cooling design, and multiple I/O ports make it suitable for integration into industrial equipment or space-constrained embedded systems.
| Processor | Product Collection | Intel 12th/13th Gen Processors | |
| Sockets Supported | FCBGA1744 | ||
| Memory specifications | Memory type | DDR4 SO-DIMM | |
| Maximum capacity | 2x 32GB | ||
| Maximum frequency | 3200 MT/s | ||
| Storage specifications | SATA | 1*SATA 3.0 (6Gb/s) | |
| M.2 | 1*M.2 Key-M 2280 | ||
| Interface | Front Panel | Ethernet | 4*RJ45 |
| Console | 1*RJ45 COM | ||
| Power | 1*Jack DC_IN | ||
| Back Panel | USB | 4*USB-A 3.0 | |
| Display | 1*HD/1*DP | ||
| SIM | 1*SIM Card slot | ||
| Antenna hole | 2*Reserved | ||
| Extension interface | mPCIe | 1*mPCIe | |
| Cooling Method | Passive Cooling, Fanless (Need air flow) | ||
| System Specifications | Chassis Size | 178*126*55 (mm) | |
| Weight | Equipment Weight 1.15 KG; Package Weight 1.75 KG (including accessories) | ||
| Power Mode | DC | 12V 7A or Higher | |
| Work Environment | Temperature | 0~50℃ | |
| Humidity | 5%~90% (Relative humidity, no condensation) | ||
