C246-NAS-ITX-MB

$89.99

C246-NAS-ITX-MB is a high-performance Mini-ITX motherboard for enterprise storage and edge computing. Based on the Intel C246 chipset, it supports the 8th-9th generation Core/Xeon E-2100 series processors (LGA1151 socket), provides dual M.2 NVMe SSD+ 8×SATA storage architecture and 4×2.5G Ethernet ports, and provides desktop-level server performance for virtualization platforms, AI reasoning and high-density NAS.

Specifications:

Model C246-NAS-ITX-MB
Processor Intel LGA1151 Socket (8th-9th Gen)
Chipset BKHD-1151NP-17-4L-MB (FCLGA1151)
BIOS AMI EFI BIOS (UEFI boot only)
Memory Slot 2x DDR4 DIMM Memory slot, Up to 64GB 2666MT/s
Storage Slot 2x M.2 NVMe 2280 SSD/8x SATA 6Gb/s
Ethernet Ports 4x RJ45 2.5GbE (Adaptive)
Ethernet Controller 4x Intel I226-V
Expansion Slot 1x PCIe x16 (Gen3)
Panel I/O 4x USB-A 3.0; 1x DP port; 1x HD port; 4x RJ45; 1x 3.5mm Jack Audio
Onboard I/O 1x USB-A 2.0; 24pin ATX+4pin ATX; 8x 7pin SATA 6Gb/s
Onboard Pins 1x F_USB3 (20pin); 1x F_PANEL; 2x CPU/SYS_FAN (4pin); 1x JLPC (9pin)
Display Chip Depends on CPU
Other functions Start auto after power restored; Wake-up on LAN; PXE; Watchdog
Board Size 170*170 (mm) m-ITX
Power Supply ATX 24pin+4pin

50 in stock

Category: Tags: , , , , Brand:

Core highlights

Server-level computing performance: supports Intel Xeon E-2100 series or Core i9 processors, optional ECC memory (Xeon platform and ECC UDIMM) to ensure data integrity.

Storage expansion breakthrough: 8 native SATA can be directly connected to HDD/SSD arrays, support hardware RAID 0/1/5/10, and build a massive storage pool. Dual M.2 NVMe 2280 can be configured as ZFS cache (accelerated small file read and write) or form RAID 0 (continuous read and write> 6GB/s).

Network and expansion capabilities: 4x 2.5GbE network ports can support LACP aggregation, VLAN isolation management/storage/backup traffic, PCIe 3.0 x16 slot can support GPU accelerator card for AI video analysis or expand 25GbE network card for data center interconnection.

Enterprise-level reliability: Support hardware-level protection, watchdog automatic reset system downtime, power-off self-restart to ensure service continuity, dual 4pin fan interface can support PWM precise temperature control.

Weight 0.65 kg
Dimensions 26 × 26 × 8 cm
Bundles

Motherboard only (no fan)
